C Type Power Press

C Type Power Press

Shital Machines Tools brand mechanical Power Presses are coming in both C frame and Pillar type versions from 2 tons to 250 tons capacity in most economical type of construction with several std/optional features such as manual/auto lubrication. systems; knockouts electronics hand safety; single/double or un-geared versions as also pneumatic feeders/ straightness and de-coilers for automation Purpose.


Specification 3 5 5 10 10 10 15 20 20 30 30 50 60 75 85 100 150 200 250 300
CRANK DIAMETER 38 51 51 60 60 60 70 76 76 83 83 95 101 115 115 127 140 158 165 175
STROKE/ MIN 2-19 MM 6-25 MM 6-38 MM 6-25 MM 6-51 MM 6-51 MM 10-51 MM 13-51 MM 13-76 MM 13-63 MM 13-89 MM 13-76 MM 13-80 MM 13-102 MM 13-102 MM 13-115 MM 13-127 MM 13-152 MM 13-165 MM 13-175 MM
SLIDE ADJUSTMENT 20 25 25 25 25 25 25 25 25 25 25 40 40 50 50 60 60 70 70 70
HOLE IN RAM 19 25 25 25 25 25 32 32 32 38 38 51 51 51 51 55 55 63 63 63
HOLE IN BED 51 63 75 76 76 76 89 89 89 102 102 127 127 178 178 191 203 216 216 228
L x W OF BED 255 X 152 305 x 178 356 x 203 356 x 203 406 x 254 406 x 254 457 x 305 457 x 305 508 x 355 508 x 355 559 x 406 660 x 406 711 x 508 711 x 508 760 x 595 813 x 558 914 x 610 965 x 660 1067 x 711 1117Γ—762
DIST. BED TO RAM 140 152 175 180 205 205 230 230 254 266 305 290 320 330 350 381 410 432 485 508
STROKE/Mill – – – – – – – – – – – – – – – – – – – –
DOUBLE GEAR (SPM) – – – – – – – 50 50 40 40 30 – – – – – – – –
SINGLE GEAR (SPM) 90 80 80 80 80 80 75 60 60 55 55 50 50 40 40 30 30 30 30 30
UN GEAR (SPM) 165 150 150 130 130 130 120 120 120 115 115 90 – – – – – – – –
H. P./ RPM (UG) 0.5 / 960 0.5/960 0.5 / 960 1/960 1-960 1/960 1.5/960 2/960 2/960 3/960 3/960 5/960 – – – – – – – –
H. P./RPM (G) 0.5/1440 0.5/1440 0.5/1440 1/1440 1/1440 1/1440 1.5/1440 2/1440 2/1440 3/1440 3/1440 5/1440 5/1440 7.5/1440 7.5/1440 10/1440 15/1440 20/1440 25/1440 30/1440
FLOOR TO TOP OF BED 520 690 690 730 730 730 740 815 844 815 856 900 900 915 915 915 915 915 915 915
WT.I1I KGS (APPOX) 150 300 350 450 525 525 700 900 1050 1100 1465 2250 2700 3500 4050 5500 6000 9500 11500 13000
