Models SL-LD1 SL-LD2
Height Of Centre (mm) 165 175
Width of Bed (mm) 238 238
Max Swing over bed (mm) 330 350
Max Swing over Slide (mm) 180 200
Spindle Bore (mm) 40 40
Spindle Nose 8 TPI 8 TPI
Spindle Speed 8 (R.P.M) 30-825 30-825
Cross Slide Travel (mm) 225 225
Lead Screw TPI 4 TPI 4 TPI
Tail Stock Sleeve MT-3 MT-3
Power Required (H.P.) 1 1

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Centre Adaptor
  • Dead Centres
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fitting
  • True Chuck & Dog Chuck
  • Quick Change Tool Post
  • Tapper Turning Attachment
  • Coolant Pump with Tank & Fittings
  • Machine Lamp
  • Rear Tool Post
  • Norton Gear Box
  • Key Way Milling Attachment
  • Tool Post Grinder
  • High Tensile Casting
  • Latest Design Head Stock
  • Hardened & Ground Bed & Spindle
