Medium Duty Lathe
Medium Duty Lathe
| Models | SL-MD1 | SL-MHD1 |
|---|---|---|
| Height Of Centre (mm) | 212 | 250 |
| Width of Bed (mm) | 280 | 280 |
| Max Swing over bed (mm) | 410 | 490 |
| Max Swing over Slide (mm) | 240 | 320 |
| Spindle Bore (mm) | 52 mm | 80 mm |
| Spindle Nose | 6 TPI | 6 TPI |
| Spindle Speed 6(R.P.M) | 40 to 550 | 40 to 550 |
| Cross Slide Travel (mm) | 240 mm | 240 |
| Lead Screw TPI | 4 TPI | 4 TPI |
| Tail Stock Sleeve | MT-4 | MT-4 |
| Power Required (H.P.) | 2 | 2 |
Standard Accessories :
- Chuck Plate
- Gear Set
- Centre Adaptor
- Dead Centres
- Dial Indicator
- Square Tool Post
- Tool Post Key
Optional Accessories :
- Steady Rest
- Follow Rest
- Face Plate
- Electrical Fitting
- True Chuck & Dog Chuck
- Quick Change Tool Post
- Tapper Turning Attachment
- Coolant Pump with Tank & Fittings
- Machine Lamp
- Rear Tool Post
- Norton Gear Box
- Key Way Attachment
- Tool Post Grinder
- High Tensile Casting
- Latest Design Head Stock
- Hardened & Ground Bed & Spindle
